TuskE(CE Version)

CE Certification Full directive CE Certification.
Multiple Vehicles Support National Standard and European Standard Pallets.
High-level Safety CE PLd level.

Project	Specifications	TuskE(CE Version)	TuskES-H(CE Version)
Basic Parameters	Size(mm)	1312x1060x170	1479x1060x295 (SLAM component can be elevated)
	Maximum Lifting Weight (kg)	800
	Self-Weight (kg)	310	340
	Fork Height (mm)	90(7mm downward floating height with loading)
	Fork Stretch Out Max Limit (mm)	1400
	Maximum Lifting Height (mm)	≤330
	Display Screen	5 inches
	Telecommunication Modes	Support dual-band 2.4G/5G
Safety Protection	Obstacle Avoidance Protection	Front double laser sensors + Rear double laser sensors
	Detection Distance of Front Laser(m)	0-3
	Mechanical Protection	Emergency stop button, Reset button, A protection strip around the whole vehicle body
	Caution Function	With voice and photoelectric alarm functions
	Fork tip protection	Photoelectric sensor detection distance≤100mm, collision switch
	Security level	PLd
Movement Capability	Navigation Mode	DM code	SLAM + DM code Dual Navigation
	Maximum Speed (Full Load/Empty Load)(m/s)	1.5/1.2
	Rated Acceleration(m/s²)	1
	Stop Accuracy	±5mm /±1°	土20mm /±2°
	Movement Mode	Two-wheel differential
	Ground Adaptation Gap Slope Step	40mm(Gap)/4°(7%)(Slope)/15mm(Step)
	Maximum Slope when the Fork Extension reach to the Maximum	2°
Lithium Battery Performance	Rated Voltage/Capacity	51.2V/30AH
	Battery Life	The times of fully charging: 1500 times (The battery capacity is guaranted to be more than 70% of the new battery)
	Battery Endurance/Charging Time	≥8H/≤2H
	Battery Type	LFP
Environment	Operating temperature(℃)	0~45
Pallet Requirement	The Width of W1 and W2 (mm)	W1≤160, 600≤W2≤900
	Pallet Length (mm)	≤1400	≤1300
	Pallet Opening Height (mm)	95-130

Links to application examples

Pallet size adaptation

Specifications	Parameters		Types
Inner Width of Slots W1(mm)	W1≤160
Outer Width of Slots W2(mm)	W2≥600
Inner Pallet Height H(mm)	95≤H≤130
Pallet Length L(mm)	≤1400(DM Code Version)	≤1300 (SLAM Version)

Tuskrobots

As China TuskE(CE Version) manufacturers and TuskE(CE Version) factory, Tuskrobots is committed to empowering intelligent logistics in smart factories, making handling simpler and more efficient.It has launched a globally unique and innovative intelligent robot product that is highly adaptable to international standard pallets for conveying and picking. Tuskrobots always insists on serving customers and pursuing customer value, sparing no effort to improve project delivery and after-sales service capability. We adhere to the customer-oriented concept with real actions, and we also continuously improve ourselves with customer feedback. To match customer usage scenarios and customer requirements, there are a variety of service products of Tuskrobots products and systems for customization or selection in the after-sales stage. Choose the service plan that suits you, we will provide service of high quality.
